1510481609
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1510481609 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1510481609 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1510481609 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | 6.5MM WTB HDR WBOSSKINK RED 6CKT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 450 pcs | ||
|---|---|---|---|---|---|
| $0.764 | $0.692 | $0.537 | |||
| 900 pcs | 1350 pcs | 5400 pcs | |||
| $0.48 | $0.424 | $0.376 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1510481609 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | 6.5MM WTB HDR WBOSSKINK RED 6CKT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 95027 pcs | Data sheet | 1510481609 Drawing151048,49 Series Prod Spec987651-1601 Brochure |
| Category | Connectors, Interconnects | Voltage Rating | - |
| Termination | Kinked Pin, Solder | Style | Board to Cable/Wire |
| Shrouding | Shrouded - 4 Wall | Series | CP-6.5 151048 |
| Row Spacing - Mating | 0.256" (6.50mm) | Pitch - Mating | 0.256" (6.50mm) |
| Packaging | Tray | Overall Contact Length | - |
| Other Names | 151048-1609 1510481609-ND WM11546 |
Operating Temperature | - |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 6 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - | Manufacturer Standard Lead Time | 21 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Polyamide (PA), Nylon, Glass Filled |
| Insulation Height | 0.630" (16.00mm) | Insulation Color | Red |
| Ingress Protection | - | Features | Board Guide |
| Fastening Type | Latch Holder | Detailed Description | Connector Header Through Hole 6 position 0.256" (6.50mm) |
| Current Rating | - | Contact Type | Male Pin |
| Contact Shape | Square | Contact Material | Copper Alloy |
| Contact Length - Post | 0.150" (3.81mm) | Contact Length - Mating | 0.348" (8.85mm) |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | 50.0µin (1.27µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Tin |
| Connector Type | Header | Applications | General Purpose, Industrial |
