1462200200
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1462200200 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1462200200 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1462200200 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | RF ANT 1.561/1.575GHZ PCB 200MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 100 pcs | 250 pcs |
|---|---|---|---|---|---|
| $1.206 | $1.075 | $0.967 | $0.882 | $0.796 | |
| 500 pcs | 1000 pcs | 2500 pcs | 5000 pcs | ||
| $0.714 | $0.602 | $0.572 | $0.55 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1462200200 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | RF ANT 1.561/1.575GHZ PCB 200MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 69148 pcs | Data sheet | 1462200200 Drawing146220-0100 SpecCombo Antennas Datasheet |
| Category | RF/IF and RFID | VSWR | - |
| Termination | Cable (200mm) - U.FL | Series | 146220 |
| Return Loss | -8dB | Power - Max | 2W |
| Packaging | Bulk | Other Names | 146220-0200 WM12964 |
| Number of Bands | 5 | Mounting Type | Adhesive |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Height (Max) | 0.032" (0.81mm) | Gain | 2.1dBi, 2.6dBi, 3dBi, 3.3dBi |
| Frequency Range | 5.15GHz ~ 5.85GHz, 3GHz ~ 6GHz | Frequency Group | Wide Band |
| Frequency (Center/Band) | 1.561GHz, 1.575GHz, 1.602GHz, 2.4GHz, 5GHz | Features | - |
| Detailed Description | 1.561GHz, 1.575GHz, 1.602GHz, 2.4GHz, 5GHz BeiDou, GLONASS, WiMax, WLAN, Wi-Fi PCB Trace RF Antenna 5.15GHz ~ 5.85GHz, 3GHz ~ 6GHz 2.1dBi, 2.6dBi, 3dBi, 3.3dBi Cable (200mm) - U.FL Adhesive | Applications | BeiDou, GLONASS, WiMax, WLAN, Wi-Fi |
| Antenna Type | PCB Trace |
