1054550101
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1054550101 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1054550101 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1054550101 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | TYPE C USB RECEPTACLE M-MOUNT-GE |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1300 pcs | 2600 pcs | 6500 pcs | ||
|---|---|---|---|---|---|
| $0.492 | $0.46 | $0.437 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1054550101 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | TYPE C USB RECEPTACLE M-MOUNT-GE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 76792 pcs | Data sheet | 105455-001 Pkg Spec1054550101 Drawing1054550101 DatasheetUSB Type C Datasheet105448-001 Prod Spec |
| Category | Connectors, Interconnects | Voltage - Rated | 300VAC/DC |
| Termination | Solder | Specifications | USB 3.1 (USB 3.1 Gen 2, Superspeed+) |
| Shielding | Shielded | Shell/Shielding Material | Steel, Stainless |
| Series | 105455 | Packaging | Tape & Reel (TR) |
| Other Names | 105455-0101 WM17904TR |
Operating Temperature | -30°C ~ 85°C |
| Number of Ports | 1 | Number of Contacts | 24 |
| Mounting Type | Surface Mount, Right Angle | Mounting Feature | Horizontal, Mid Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 10000 |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 13 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Color | Black |
| Ingress Protection | - | Gender | Receptacle |
| Features | - | Detailed Description | USB - C USB 3.1 (USB 3.1 Gen 2, Superspeed+) Receptacle Connector 24 Position Surface Mount, Right Angle |
| Current Rating | 0.25A, 1.25A, 5A | Contact Finish | Gold |
| Connector Type | USB - C |
