0746420001
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 0746420001 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 0746420001 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 0746420001 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN RCPT 8POS R/A PCB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 0746420001 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | CONN RCPT 8POS R/A PCB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5819 pcs | Data sheet | 74642-2001, 2 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 50V |
| Termination | Press-Fit | Series | 74642 |
| Pitch | 0.246" (6.25mm) | Packaging | Tray |
| Other Names | 074642-0001 74642-0001 746420001 WM8585 |
Operating Temperature | -40°C ~ 85°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 8 | Number of Columns | 4 |
| Mounting Type | Board Edge, Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Board Guide | Current Rating | 1A |
| Contact Layout, Typical | 8 Coax | Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Finish | Gold | Connector Usage | - |
| Connector Type | Receptacle, Female Sockets | Connector Style | Coax |
| Color | Natural |
