0732761501
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 0732761501 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 0732761501 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 0732761501 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN N JACK STR 50 OHM CRIMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $4.828 | $4.389 | $4.279 | $3.95 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $3.73 | $3.401 | $3.182 | $2.918 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 0732761501 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | CONN N JACK STR 50 OHM CRIMP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 13094 pcs | Data sheet | 73276150x Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 1000V |
| Shield Termination | Crimp | Series | 73276 |
| Packaging | Bulk | Other Names | 073276-1501 73276-1501 732761501 WM9545 |
| Operating Temperature | -55°C ~ 125°C | Number of Ports | 1 |
| Mounting Type | Panel Mount | Mounting Feature | Bulkhead - Front Side Nut |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Ingress Protection | IP68 - Dust Tight, Waterproof |
| Includes | 6 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Heat Shrink, 1 Lockwasher, 1 Nut | Impedance | 50 Ohm |
| Housing Color | Silver | Frequency - Max | 11GHz |
| Features | - | Fastening Type | Threaded |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | Detailed Description | N Type Connector Jack, Female Socket 50 Ohm Panel Mount Crimp |
| Contact Termination | Crimp | Connector Type | Jack, Female Socket |
| Connector Style | N Type | Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper | Cable Group | RG-316, Belden 7805 |
| Body Material | Brass | Body Finish | Nickel |
