0731315013
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 0731315013 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 0731315013 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 0731315013 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN BNC RCPT STR 50 OHM PCB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.917 | $0.833 | $0.782 | $0.748 | $0.714 | |
| 324 pcs | 648 pcs | 1296 pcs | 2592 pcs | ||
| $0.646 | $0.595 | $0.51 | $0.476 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 0731315013 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | CONN BNC RCPT STR 50 OHM PCB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 69365 pcs | Data sheet | 73131-5013 Drawing |
| Category | Connectors, Interconnects | Voltage Rating | 1000V |
| Shield Termination | Solder | Series | 73131 |
| Packaging | Tray | Other Names | 073131-5013 073131-5013-E 0731315013-E 73131-5013 73131-5013-E 731315013 731315013-E SD-73131-5013 WM5513 |
| Operating Temperature | -65°C ~ 95°C | Number of Ports | 1 |
| Mounting Type | Panel Mount, Through Hole | Mounting Feature | Bulkhead - Front Side Nut |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mating Cycles | 500 |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insertion Loss | - | Ingress Protection | - |
| Includes | 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut | Impedance | 50 Ohm |
| Housing Color | Silver, White | Frequency - Max | 10GHz |
| Features | Isolated | Fastening Type | Bayonet Lock |
| Dielectric Material | Polypropylene (PP) | Detailed Description | BNC Connector Receptacle, Female Socket 50 Ohm Panel Mount, Through Hole Solder |
| Contact Termination | Solder | Connector Type | Receptacle, Female Socket |
| Connector Style | BNC | Center Contact Plating | Gold |
| Center Contact Material | Phosphor Bronze | Cable Group | - |
| Body Material | Zinc Alloy | Body Finish | Nickel |
