0556500788
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 0556500788 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 0556500788 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 0556500788 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN PLUG BTB 70POS DL VERT SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $1.295 | $1.242 | $1.139 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $1.087 | $1.035 | $0.906 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | 0556500788 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | CONN PLUG BTB 70POS DL VERT SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 40341 pcs | Data sheet | Prod Spec55650 Series Drawing |
| Category | Connectors, Interconnects | Series | SlimStack 55650 |
| Pitch | 0.020" (0.50mm) | Packaging | Cut Tape (CT) |
| Other Names | WM8780CT | Number of Rows | 2 |
| Number of Positions | 70 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mated Stacking Heights | 2mm |
| Manufacturer Standard Lead Time | 14 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Above Board | 0.063" (1.60mm) | Features | Solder Retention |
| Detailed Description | 70 Position Connector Plug, Outer Shroud Contacts Surface Mount Gold | Contact Finish Thickness | 10.0µin (0.25µm) |
| Contact Finish | Gold | Connector Type | Plug, Outer Shroud Contacts |
