0480749101
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 0480749101 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 0480749101 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 0480749101 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN MAGJACK 1PORT 100BASE-T SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 100 pcs | 300 pcs | 500 pcs | 1000 pcs | |
|---|---|---|---|---|---|
| $3.794 | $3.459 | $3.236 | $2.968 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 0480749101 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | CONN MAGJACK 1PORT 100BASE-T SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10408 pcs | Data sheet | 0480749101 Drawing48074-006 Prod Spec |
| Category | Connectors, Interconnects | Termination | Solder |
| Tab Direction | Up | Shielding | Shielded, EMI Finger |
| Shield Material | Brass | Series | 48074 |
| Packaging | Tape & Reel (TR) | Other Names | 048074-9101 0480749101-ND 48074-9101 480749101 WM17279TR |
| Orientation | 90° Angle (Right) | Operating Temperature | -40°C ~ 85°C |
| Number of Rows | 1 | Number of Ports | 1 |
| Number of Cores per Jack | 4 | Mounting Type | Surface Mount |
| Manufacturer Standard Lead Time | 11 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| LED Color | Green - Yellow | Housing Material | Thermoplastic |
| Height Above Board | 0.524" (13.31mm) | Features | Board Guide |
| Detailed Description | 1 Port RJ45 Magjack Connector Surface Mount 10/100 Base-T, AutoMDIX | Contact Material | Phosphor Bronze |
| Contact Finish Thickness | 30.0µin (0.76µm) | Contact Finish | Gold |
| Connector Type | RJ45 | Applications | 10/100 Base-T, AutoMDIX |
