0472570001
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 0472570001 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 0472570001 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 0472570001 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | CONN JACK STEREO 3.5MM PCB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.407 | $0.357 | $0.336 | $0.322 | $0.308 | |
| 250 pcs | 500 pcs | 1000 pcs | 2500 pcs | ||
| $0.28 | $0.252 | $0.224 | $0.203 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 0472570001 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | CONN JACK STEREO 3.5MM PCB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 101741 pcs | Data sheet | 472570001 |
| Category | Connectors, Interconnects | Voltage - Rated | 12VDC |
| Thread Size | - | Termination | Solder |
| Signal Lines | Stereo (3 Conductor, TRS) | Shielding | Unshielded |
| Series | 47257 | Panel Hole Size | - |
| Packaging | Tube | Other Names | 047257-0001 0472570001-ND 47257-0001 472570001 WM17366 |
| Operating Temperature | -40°C ~ 85°C | Number of Positions/Contacts | 3 Conductors, 4 Contacts |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mating Length/Depth | - | Manufacturer Standard Lead Time | 11 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Internal Switch(s) | Single Switch |
| Insulation Color | - | Industry Recognized Mating Diameter | 3.50mm (0.141", 1/8", Mini Plug) - Headphone |
| Includes | - | Housing Material | Polyamide (PA), Nylon, Glass Filled |
| Gender | Female | Features | Board Guide |
| Detailed Description | 3.50mm (0.141", 1/8", Mini Plug) - Headphone Phone Jack Stereo (3 Conductor, TRS) Connector Solder | Current Rating | 1A |
| Contact Material - Plating | Gold | Contact Material | Brass, Phosphor Bronze |
| Connector Type | Phone Jack | Cable Opening | - |
| Body Material | - | Body Color | Black |
| Actual Diameter | 0.140" (3.56mm) |
