0447692402
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 0447692402 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 0447692402 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 0447692402 |
|---|---|
| Manufacturer | Affinity Medical Technologies - a Molex company |
| Description | MICRO-FIT BMI VT HDR F DR 15AU |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 630 pcs | 1260 pcs |
|---|---|---|---|---|---|
| $3.166 | $3.028 | $2.546 | $2.133 | $1.886 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 0447692402 | Manufacturer | Affinity Medical Technologies - a Molex company |
|---|---|---|---|
| Description | MICRO-FIT BMI VT HDR F DR 15AU | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 19277 pcs | Data sheet | 44769-xx0xMicro-Fit BMI SpecMicro-Fit 3.0™ Datasheet |
| Category | Connectors, Interconnects | Voltage Rating | 250VAC |
| Termination | Solder | Style | Board to Board or Cable |
| Series | Micro-Fit 3.0 BMI 44769 | Row Spacing - Mating | 0.118" (3.00mm) |
| Pitch - Mating | 0.118" (3.00mm) | Packaging | Tray |
| Other Names | 0447-69-2402 044769-2402 0447692402-ND 44769-2402 447692402 WM14932 |
Operating Temperature | -40°C ~ 105°C |
| Number of Rows | 2 | Number of Positions Loaded | All |
| Number of Positions | 24 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | 16.86mm | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insulation Material | Liquid Crystal Polymer (LCP), Glass Filled |
| Insulation Height | 0.535" (13.60mm) | Insulation Color | Black |
| Ingress Protection | - | Features | Board Guide |
| Fastening Type | Push-Pull | Detailed Description | 24 Position Receptacle Connector 0.118" (3.00mm) Through Hole Gold |
| Current Rating | 5A | Contact Type | Female Socket |
| Contact Shape | Square | Contact Material | Phosphor Bronze |
| Contact Length - Post | 0.134" (3.40mm) | Contact Finish Thickness - Post | 100.0µin (2.54µm) |
| Contact Finish Thickness - Mating | 15.0µin (0.38µm) | Contact Finish - Post | Tin |
| Contact Finish - Mating | Gold | Connector Type | Receptacle |
| Applications | General Purpose, Telecommunications |
