ASMPH-0806-1R0M-T
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ASMPH-0806-1R0M-T with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ASMPH-0806-1R0M-T with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ASMPH-0806-1R0M-T |
|---|---|
| Manufacturer | Abracon Corporation |
| Description | FIXED IND 1UH 1.4A 90 MOHM SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 3000 pcs | 6000 pcs | 15000 pcs | 30000 pcs | 75000 pcs |
|---|---|---|---|---|---|
| $0.045 | $0.042 | $0.041 | $0.04 | $0.038 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | ASMPH-0806-1R0M-T | Manufacturer | Abracon Corporation |
|---|---|---|---|
| Description | FIXED IND 1UH 1.4A 90 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 534950 pcs | Data sheet | ASMPH-0806 DrawingASMPH-0806 |
| Category | Inductors, Coils, Chokes | Type | Multilayer |
| Tolerance | ±20% | Supplier Device Package | 0806 (2016 Metric) |
| Size / Dimension | 0.079" L x 0.063" W (2.00mm x 1.60mm) | Shielding | Shielded |
| Series | ASMPH-0806 | Ratings | - |
| Q @ Freq | - | Packaging | Tape & Reel (TR) |
| Package / Case | 0806 (2016 Metric) | Other Names | 535-12276-2 |
| Operating Temperature | -40°C ~ 85°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | Ferrite |
| Manufacturer Standard Lead Time | 11 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 1MHz | Inductance | 1µH |
| Height - Seated (Max) | 0.039" (1.00mm) | Frequency - Self Resonant | 70MHz |
| Detailed Description | 1µH Shielded Multilayer Inductor 1.4A 90 mOhm 0806 (2016 Metric) | DC Resistance (DCR) | 90 mOhm |
| Current Rating | 1.4A | Current - Saturation | 1.2A |
