TV-4G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy TV-4G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy TV-4G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | TV-4G |
|---|---|
| Manufacturer | Aavid Thermalloy |
| Description | HEATSINK TO-126 BLACK |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | ||
|---|---|---|---|---|---|
| $1.987 | $1.931 | $1.61 | |||
| 500 pcs | 1000 pcs | 5000 pcs | |||
| $1.395 | $1.368 | $1.341 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | TV-4G | Manufacturer | Aavid Thermalloy |
|---|---|---|---|
| Description | HEATSINK TO-126 BLACK | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 25047 pcs | Data sheet | Standard Heatsinks Catalog |
| Category | Fans, Thermal Management | Type | Board Level |
| Thermal Resistance @ Natural | 12°C/W @ 300 LFM | Thermal Resistance @ Forced Air Flow | 3W @ 65°C |
| Size, Supplied | - | Shielding | 0.748" (19.00mm) |
| Shape | Rectangular, Fins | Series | - |
| Product Type | Black Anodized | Power Dissipation @ Temperature Rise | 0.748" (19.00mm) |
| Other Names | 033702 | Material Thickness | 0.866" (22.00mm) |
| Material Finish | 21.6°C/W | Material | Aluminum |
| Manufacturer Part Number | TV-4G | Height Off Base (Height of Fin) | Bolt On |
| Expanded Description | Heat Sink TO-126 Aluminum 3W @ 65°C Board Level | Description | HEATSINK TO-126 BLACK |
| Attachment Method | TO-126 |
