7141DG
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 7141DG with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 7141DG with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 7141DG |
|---|---|
| Manufacturer | Aavid Thermalloy |
| Description | BOARD LEVEL HEATSINK .515"TO-220 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.374 | $0.357 | $0.347 | $0.338 | $0.319 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.30 | $0.282 | $0.263 | $0.254 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 7141DG | Manufacturer | Aavid Thermalloy |
|---|---|---|---|
| Description | BOARD LEVEL HEATSINK .515"TO-220 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 76938 pcs | Data sheet | 7141DGStandard Heatsinks Catalog |
| Category | Fans, Thermal Management | Width | 0.520" (13.21mm) |
| Type | Board Level, Vertical | Thermal Resistance @ Natural | 20.30°C/W |
| Thermal Resistance @ Forced Air Flow | 10.00°C/W @ 200 LFM | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | 1.0W @ 30°C |
| Package Cooled | TO-220 | Other Names | 042648 7141DG-ND HS414 |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Finish | Tin |
| Material | Copper | Manufacturer Standard Lead Time | 7 Weeks |
| Length | 0.780" (19.81mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.515" (13.08mm) | Diameter | - |
| Detailed Description | Heat Sink TO-220 Copper 1.0W @ 30°C Board Level, Vertical | Attachment Method | Clip and PC Pin |
