7136DG
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 7136DG with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 7136DG with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 7136DG |
|---|---|
| Manufacturer | Aavid Thermalloy |
| Description | BOARD LEVEL HEATSINK .515"TO-220 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.307 | $0.292 | $0.277 | $0.27 | $0.266 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.248 | $0.233 | $0.212 | $0.204 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 7136DG | Manufacturer | Aavid Thermalloy |
|---|---|---|---|
| Description | BOARD LEVEL HEATSINK .515"TO-220 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 115741 pcs | Data sheet | Standard Heatsinks Catalog713xDG |
| Category | Fans, Thermal Management | Width | 0.520" (13.21mm) |
| Type | Board Level, Vertical | Thermal Resistance @ Natural | 19.70°C/W |
| Thermal Resistance @ Forced Air Flow | 6.00°C/W @ 500 LFM | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | 1.0W @ 30°C |
| Package Cooled | TO-220 | Other Names | 042597 7136DG-ND HS409 |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Finish | Tin |
| Material | Copper | Length | 0.848" (21.55mm) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height Off Base (Height of Fin) | 0.515" (13.08mm) |
| Diameter | - | Detailed Description | Heat Sink TO-220 Copper 1.0W @ 30°C Board Level, Vertical |
| Attachment Method | Clip and PC Pin |
