6022BG
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 6022BG with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 6022BG with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 6022BG |
|---|---|
| Manufacturer | Aavid Thermalloy |
| Description | HEATSINK TO-220 STAGGERED FIN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.681 | $0.649 | $0.632 | $0.615 | $0.58 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.546 | $0.512 | $0.478 | $0.461 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 6022BG | Manufacturer | Aavid Thermalloy |
|---|---|---|---|
| Description | HEATSINK TO-220 STAGGERED FIN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 81663 pcs | Data sheet | 6022BGStandard Heatsinks Catalog |
| Category | Fans, Thermal Management | Width | 0.875" (22.22mm) |
| Type | Board Level, Vertical | Thermal Resistance @ Natural | 16.70°C/W |
| Thermal Resistance @ Forced Air Flow | 6.00°C/W @ 400 LFM | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | 2.0W @ 40°C |
| Package Cooled | TO-220 | Other Names | 043130 |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 7 Weeks |
| Length | 1.210" (30.73mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.250" (6.35mm) | Diameter | - |
| Detailed Description | Heat Sink TO-220 Aluminum 2.0W @ 40°C Board Level, Vertical | Attachment Method | Bolt On and PC Pin |
