507102B00000G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 507102B00000G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 507102B00000G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 507102B00000G |
|---|---|
| Manufacturer | Aavid Thermalloy |
| Description | HEATSINK TO-220 EXT CAP 2W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.248 | $0.238 | $0.226 | $0.22 | $0.217 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.202 | $0.191 | $0.173 | $0.167 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 507102B00000G | Manufacturer | Aavid Thermalloy |
|---|---|---|---|
| Description | HEATSINK TO-220 EXT CAP 2W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 129176 pcs | Data sheet | Standard Heatsinks Catalog50(6,7)xx2B0xx00G |
| Category | Fans, Thermal Management | Width | 1.750" (44.45mm) |
| Type | Board Level | Thermal Resistance @ Natural | 15.60°C/W |
| Thermal Resistance @ Forced Air Flow | 5.00°C/W @ 200 LFM | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | 4.0W @ 40°C |
| Package Cooled | TO-220 | Other Names | 001343 507102B00000 5071B 6071B HS113 |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 7 Weeks |
| Length | 0.700" (17.78mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.500" (12.70mm) | Diameter | - |
| Detailed Description | Heat Sink TO-220 Aluminum 4.0W @ 40°C Board Level | Attachment Method | Bolt On |
