504102B00000G
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 504102B00000G with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 504102B00000G with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 504102B00000G |
|---|---|
| Manufacturer | Aavid Thermalloy |
| Description | HEATSINK TO-220 PWR CLR .700" |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.243 | $0.232 | $0.22 | $0.214 | $0.211 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.197 | $0.185 | $0.168 | $0.162 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | 504102B00000G | Manufacturer | Aavid Thermalloy |
|---|---|---|---|
| Description | HEATSINK TO-220 PWR CLR .700" | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 130843 pcs | Data sheet | 504x02B00000GStandard Heatsinks Catalog |
| Category | Fans, Thermal Management | Width | 0.779" (19.80mm) |
| Type | Board Level | Thermal Resistance @ Natural | 15.60°C/W |
| Thermal Resistance @ Forced Air Flow | 6.00°C/W @ 300 LFM | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | 2.0W @ 40°C |
| Package Cooled | TO-220 | Other Names | 001234 5041 504102B00000 5041B HS104-1 |
| Moisture Sensitivity Level (MSL) | Not Applicable | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 7 Weeks |
| Length | 0.701" (17.80mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.850" (21.60mm) | Diameter | - |
| Detailed Description | Heat Sink TO-220 Aluminum 2.0W @ 40°C Board Level | Attachment Method | Bolt On |
