V8502A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy V8502A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy V8502A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | V8502A |
|---|---|
| Manufacturer | ASSMANN WSW Components |
| Description | HEATSINK TO-220 30X25.40MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.246 | $0.236 | $0.224 | $0.218 | $0.215 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.20 | $0.189 | $0.171 | $0.165 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | V8502A | Manufacturer | ASSMANN WSW Components |
|---|---|---|---|
| Description | HEATSINK TO-220 30X25.40MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 132770 pcs | Data sheet | V8502A Drawing |
| Category | Fans, Thermal Management | Width | 1.000" (25.40mm) |
| Type | Board Level, Vertical | Thermal Resistance @ Natural | 20.00°C/W |
| Thermal Resistance @ Forced Air Flow | 8.00°C/W @ 600 LFM | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | 3.0W @ 60°C |
| Package Cooled | TO-220 | Other Names | A10758 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 20 Weeks |
| Length | 1.181" (30.00mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.500" (12.70mm) | Diameter | - |
| Detailed Description | Heat Sink TO-220 Aluminum 3.0W @ 60°C Board Level, Vertical | Attachment Method | Bolt On and PC Pin |
