V7236A1
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy V7236A1 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy V7236A1 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | V7236A1 |
|---|---|
| Manufacturer | ASSMANN WSW Components |
| Description | HEATSINK TO-220 19.05X13.21MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | 100 pcs |
|---|---|---|---|---|---|
| $0.088 | $0.084 | $0.08 | $0.078 | $0.077 | |
| 250 pcs | 500 pcs | 1000 pcs | 5000 pcs | ||
| $0.071 | $0.067 | $0.061 | $0.059 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | V7236A1 | Manufacturer | ASSMANN WSW Components |
|---|---|---|---|
| Description | HEATSINK TO-220 19.05X13.21MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 319118 pcs | Data sheet | V7236x Drawing |
| Category | Fans, Thermal Management | Width | 0.520" (13.21mm) |
| Type | Board Level | Thermal Resistance @ Natural | 28.00°C/W |
| Thermal Resistance @ Forced Air Flow | - | Shape | Rectangular, Fins |
| Series | - | Power Dissipation @ Temperature Rise | - |
| Package Cooled | TO-220 | Other Names | A10762 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Finish | Black Anodized |
| Material | Aluminum | Manufacturer Standard Lead Time | 20 Weeks |
| Length | 0.750" (19.05mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height Off Base (Height of Fin) | 0.250" (6.35mm) | Diameter | - |
| Detailed Description | Heat Sink TO-220 Aluminum Board Level | Attachment Method | Bolt On |
