Home > Products > Filters > Common Mode Chokes > CM7560-126

CM7560-126

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy CM7560-126 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	CM7560-126
Manufacturer	API Delevan
Description	CMC 12MH 700MA 2LN TH
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant

~~In Stock~~ 13605 pcs
Reference Price (In US Dollars)	500 pcs
Reference Price (In US Dollars)	$2.748

Product parameter
Data sheet

Product parameter

Part Number	CM7560-126	Manufacturer	API Delevan
Description	CMC 12MH 700MA 2LN TH	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	13605 pcs	Data sheet	CM7560(R) Series
Category	Filters	Voltage Rating - DC	-
Voltage Rating - AC	-	Size / Dimension	1.071" L x 0.858" W (27.20mm x 21.80mm)
Series	CM7560	Ratings	-
Packaging	Bulk	Package / Case	Vertical, 4 PC Pin
Other Names	CM7560-126 BULK 25	Operating Temperature	-55°C ~ 125°C
Number of Lines	2	Mounting Type	Through Hole
Manufacturer Standard Lead Time	9 Weeks	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Inductance @ Frequency	12mH @ 1kHz	Height (Max)	0.861" (21.86mm)
Filter Type	-	Features	-
Detailed Description	12mH @ 1kHz 2 Line Common Mode Choke Through Hole 700mA DCR 900 mOhm	DC Resistance (DCR) (Max)	900 mOhm
Current Rating (Max)	700mA	Approvals	-
