HSC2503R3J
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy HSC2503R3J with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy HSC2503R3J with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | HSC2503R3J |
|---|---|
| Manufacturer | AMP Connectors / TE Connectivity |
| Description | RES CHAS MNT 3.3 OHM 5% 250W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | ||
|---|---|---|---|---|---|
| $17.024 | $15.077 | $13.861 | |||
| 50 pcs | 100 pcs | 250 pcs | |||
| $13.132 | $12.646 | $12.159 | |||
- Product parameter
- Data sheet
Product parameter
| Part Number | HSC2503R3J | Manufacturer | AMP Connectors / TE Connectivity |
|---|---|---|---|
| Description | RES CHAS MNT 3.3 OHM 5% 250W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2637 pcs | Data sheet | HSC250 DrawingHS Series Datasheet |
| Category | Resistors | Tolerance | ±5% |
| Temperature Coefficient | ±50ppm/°C | Size / Dimension | 4.291" L x 2.874" W (109.00mm x 73.00mm) |
| Series | HS, CGS | Resistance | 3.3 Ohms |
| Power (Watts) | 250W | Packaging | Bulk |
| Package / Case | Axial, Box | Other Names | 2-1630024-3 216300243 A103848 |
| Operating Temperature | -55°C ~ 200°C | Mounting Feature | Flanges |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Style | Terminal Screw Type | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | 1.654" (42.00mm) | Features | - |
| Failure Rate | - | Detailed Description | 3.3 Ohms ±5% 250W Wirewound Chassis Mount Resistor |
| Composition | Wirewound | Coating, Housing Type | Aluminum |
