Home > Products > Connectors, Interconnects > Rectangular Connectors - Headers, Male Pins > 8-2232000-3

8-2232000-3

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 8-2232000-3 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	8-2232000-3
Manufacturer	TE Connectivity AMP Connectors
Description	3P, RAST 5 TAB HEADER, THV
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 212058 pcs
Reference Price (In US Dollars)	4000 pcs
Reference Price (In US Dollars)	$0.113

Product parameter
Data sheet

Product parameter

Part Number	8-2232000-3	Manufacturer	TE Connectivity AMP Connectors
Description	3P, RAST 5 TAB HEADER, THV	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	212058 pcs	Data sheet	1971845, 1846, 1895, 1896 Drawing
Category	Connectors, Interconnects	Termination	Solder
Stacking Direction	Tab	Shrouding	0.197" (5.00mm)
Series	-	Row Spacing - Mating	Shrouded
RoHS Status	Bulk	Other Names	A116967
Number of Rows	1	Number of Positions	3
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material - Insulation	All	Manufacturer Standard Lead Time	16 Weeks
Manufacturer Part Number	8-2232000-3	Features	Board Guide
Expanded Description	3 Positions Header Connector 0.197" (5.00mm) Through Hole Tin	Description	3P, RAST 5 TAB HEADER, THV
Current - Max/Contact	Latch Holder	Contact Length - Post	-
Contact Length - Mating	-	Contact Finish Thickness - Mating	Tin
Contact Finish - Post	-	Connector Type	Header
Actual Diameter	Black
