36502CR15JTDG
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 36502CR15JTDG with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 36502CR15JTDG with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 36502CR15JTDG |
|---|---|
| Manufacturer | AMP Connectors / TE Connectivity |
| Description | FIXED IND 150NH 580MA 700 MOHM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $0.176 | $0.153 | $0.109 | $0.092 | $0.074 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | 36502CR15JTDG | Manufacturer | AMP Connectors / TE Connectivity |
|---|---|---|---|
| Description | FIXED IND 150NH 580MA 700 MOHM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 314588 pcs | Data sheet | 3650 (2C) Series Drawing3650 Series Datasheet |
| Category | Inductors, Coils, Chokes | Type | Wirewound |
| Tolerance | ±5% | Supplier Device Package | 1411 (2927 Metric) |
| Size / Dimension | 0.115" L x 0.110" W (2.92mm x 2.79mm) | Shielding | Unshielded |
| Series | 3650, Sigma Inductors | Ratings | - |
| Q @ Freq | 45 @ 100MHz | Packaging | Original-Reel® |
| Package / Case | Nonstandard | Other Names | A103744DKR |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Core | - |
| Manufacturer Standard Lead Time | 28 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance Frequency - Test | 25MHz | Inductance | 150nH |
| Height - Seated (Max) | 0.083" (2.10mm) | Frequency - Self Resonant | 850MHz |
| Detailed Description | 150nH Unshielded Wirewound Inductor 580mA 700 mOhm Max Nonstandard | DC Resistance (DCR) | 700 mOhm Max |
| Current Rating | 580mA | Current - Saturation | - |
