1630012-3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 1630012-3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 1630012-3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 1630012-3 |
|---|---|
| Manufacturer | AMP Connectors / TE Connectivity |
| Description | RES CHAS MNT 15 OHM 5% 150W |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 1630012-3 | Manufacturer | AMP Connectors / TE Connectivity |
|---|---|---|---|
| Description | RES CHAS MNT 15 OHM 5% 150W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5182 pcs | Data sheet | 1630012 DrawingHS Series Datasheet |
| Category | Resistors | Tolerance | ±5% |
| Temperature Coefficient | ±50ppm/°C | Size / Dimension | 3.858" L x 1.870" W (98.00mm x 47.50mm) |
| Series | HS, CGS | Resistance | 15 Ohms |
| Power (Watts) | 150W | Packaging | Tray |
| Package / Case | Axial, Box | Other Names | HSC15015RJ |
| Operating Temperature | -55°C ~ 200°C | Mounting Feature | Flanges |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Style | Solder Lugs |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 1.024" (26.00mm) |
| Features | - | Failure Rate | - |
| Detailed Description | 15 Ohms ±5% 150W Wirewound Chassis Mount Resistor | Composition | Wirewound |
| Coating, Housing Type | Aluminum |
