103904-3
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 103904-3 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 103904-3 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 103904-3 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | CONN HEADER RT/A .100 4POS 30AU |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Reference Price (In US Dollars) | 3024 pcs | ||||
|---|---|---|---|---|---|
| $0.273 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 103904-3 | Manufacturer | TE Connectivity AMP Connectors |
|---|---|---|---|
| Description | CONN HEADER RT/A .100 4POS 30AU | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 69943 pcs | Data sheet | 103904 Drawing |
| Category | Connectors, Interconnects | Voltage - DC Spark Over (Nom) | Brass |
| Type Attributes | - | Termination | Solder |
| Style | Board to Board or Cable | Stacking Direction | Male Pin |
| Shrouding | 0.100" (2.54mm) | Shield Termination | Square |
| Series | AMPMODU MTE | Row Spacing - Mating | Shrouded - 4 Wall |
| RoHS Status | Tube | Ripple Current - Low Frequency | Automotive, General Purpose, Medical, Telecommunications |
| Pitch - Connector | - | Overall Contact Length | 0.130" (3.30mm) |
| Other Names | 103904-3-ND A28580 |
Operating Temperature | -65°C ~ 105°C |
| Number of Rows | 1 | Number of Positions | 4 |
| Number of Contacts | 100µin (2.54µm) | Mounting Type | Through Hole, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Material - Insulation | All | Manufacturer Standard Lead Time | 12 Weeks |
| Manufacturer Part Number | 103904-3 | Length - Post (Mating) | - |
| Insulation Material | Tin-Lead | Insulation Height | - |
| Features | Board Lock, Keying Slot | Expanded Description | 4 Positions Header Connector 0.100" (2.54mm) Through Hole, Right Angle Gold |
| Description | CONN HEADER RT/A .100 4POS 30AU | Current Rating | 3A |
| Current - Max/Contact | Latch Holder | Contact Length - Post | 0.230" (5.84mm) |
| Contact Length - Mating | - | Contact Finish Thickness - Post | Thermoplastic |
| Contact Finish Thickness - Mating | Gold | Contact Finish - Post | 30µin (0.76µm) |
| Contact Finish - Mating | 0.200" (5.08mm) | Connector Type | Header |
| Actual Diameter | Black |
