NLAS6233MUTBG
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NLAS6233MUTBG with confidence from Components-World.HK, 1 Year Warranty
Dowload NLAS6233MUTBG Details in PDFSee Product Specifications for product details.
Buy NLAS6233MUTBG with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | NLAS6233MUTBG |
|---|---|
| Manufacturer | AMI Semiconductor / ON Semiconductor |
| Description | IC SWITCH DUAL DPDT 16UQFN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | NLAS6233MUTBG | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | IC SWITCH DUAL DPDT 16UQFN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4715 pcs | Data sheet | NLAS6233 |
| Category | Integrated Circuits (ICs) | Voltage - Supply, Single (V+) | 2.7 V ~ 4.5 V |
| Voltage - Supply, Dual (V±) | - | Switch Time (Ton, Toff) (Max) | 17ns, 9ns |
| Switch Circuit | DPDT | Supplier Device Package | 10-UQFN (1.4x1.8) |
| Series | - | Packaging | Tape & Reel (TR) |
| Package / Case | 10-UFQFN | Operating Temperature | -40°C ~ 85°C (TA) |
| On-State Resistance (Max) | 550 mOhm | Number of Circuits | 2 |
| Multiplexer/Demultiplexer Circuit | 2:2 | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Detailed Description | 2 Circuit IC Switch 2:2 550 mOhm 10-UQFN (1.4x1.8) |
| Current - Leakage (IS(off)) (Max) | 1µA | Crosstalk | -98dB @ 100kHz |
| Charge Injection | - | Channel-to-Channel Matching (ΔRon) | 190 mOhm |
| Channel Capacitance (CS(off), CD(off)) | 45pF | Base Part Number | NLAS6233 |
| -3db Bandwidth | 36MHz |
