Home > Products > Integrated Circuits (ICs) > PMIC - Power Distribution Switches, Load Drivers > NCV330MUTBG

NCV330MUTBG

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NCV330MUTBG with confidence from Components-World.HK, 1 Year Warranty

Dowload NCV330MUTBG Details in PDF

Request a Quote

Part Number	NCV330MUTBG
Manufacturer	AMI Semiconductor / ON Semiconductor
Description	IC LOAD SWITCH 3A SOFT ST 4UDFN
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 202939 pcs
Reference Price (In US Dollars)	3000 pcs
Reference Price (In US Dollars)	$0.108

Product parameter
Data sheet

Product parameter

Part Number	NCV330MUTBG	Manufacturer	AMI Semiconductor / ON Semiconductor
Description	IC LOAD SWITCH 3A SOFT ST 4UDFN	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	202939 pcs	Data sheet	NCV330
Category	Integrated Circuits (ICs)	Voltage - Supply (Vcc/Vdd)	-
Voltage - Load	1.8 V ~ 5.5 V	Switch Type	General Purpose
Supplier Device Package	4-UDFN (1.2x1.6)	Series	-
Rds On (Typ)	26 mOhm	Ratio - Input:Output	1:1
Packaging	Tape & Reel (TR)	Package / Case	4-UFDFN Exposed Pad
Output Type	N-Channel	Output Configuration	High Side
Operating Temperature	-40°C ~ 85°C (TA)	Number of Outputs	1
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	5 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Interface	On/Off
Input Type	-	Features	Slew Rate Controlled
Fault Protection	-	Current - Output (Max)	3A
