Home > Products > Development Boards, Kits, Programmers > Evaluation Boards - DC/DC & AC/DC (Off-Line) S > NCP1562-100WGEVB

NCP1562-100WGEVB

NCP1562-100WGEVB

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy NCP1562-100WGEVB with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	NCP1562-100WGEVB
Manufacturer	AMI Semiconductor / ON Semiconductor
Description	BOARD EVAL FOR NCP1562-100W
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 313 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$116.179

Product parameter
Data sheet

Product parameter

Part Number	NCP1562-100WGEVB	Manufacturer	AMI Semiconductor / ON Semiconductor
Description	BOARD EVAL FOR NCP1562-100W	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	313 pcs	Data sheet	NCP1562-100WGEVB Manual
Category	Development Boards, Kits, Programmers	Voltage - Output	3.3V
Voltage - Input	33 V ~ 76 V	Utilized IC / Part	NCP1562
Supplied Contents	Board(s)	Series	-
Regulator Topology	Buck	Power - Output	100W
Outputs and Type	1, Non-Isolated	Other Names	NCP1562-100WGEVBOS
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Main Purpose	DC/DC, Step Down
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Frequency - Switching	350kHz
Detailed Description	NCP1562 - DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board	Current - Output	30A
Board Type	Fully Populated
