LB1863M-TLM-H
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy LB1863M-TLM-H with confidence from Components-World.HK, 1 Year Warranty
Dowload LB1863M-TLM-H Details in PDFSee Product Specifications for product details.
Buy LB1863M-TLM-H with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | LB1863M-TLM-H |
|---|---|
| Manufacturer | AMI Semiconductor / ON Semiconductor |
| Description | IC MOTOR DRIVER ON/OFF 14MFP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | LB1863M-TLM-H | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | IC MOTOR DRIVER ON/OFF 14MFP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4590 pcs | Data sheet | LB1863M |
| Category | Integrated Circuits (ICs) | Voltage - Supply | 6.4 V ~ 7 V |
| Voltage - Load | 24V | Technology | Bipolar |
| Supplier Device Package | 14-SOIC / 14MFPS | Series | - |
| Rds On (Typ) | - | Packaging | Tape & Reel (TR) |
| Package / Case | 14-LSOP (0.173", 4.40mm Width) | Output Configuration | Half Bridge (2) |
| Operating Temperature | -30°C ~ 80°C (TA) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Load Type | Inductive |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Interface | Logic |
| Features | - | Fault Protection | Over Temperature |
| Detailed Description | Half Bridge (2) Driver DC Motors, General Purpose Bipolar 14-SOIC / 14MFPS | Current - Peak Output | - |
| Current - Output / Channel | 1.5A | Base Part Number | LB1863 |
| Applications | DC Motors, General Purpose |
