FDQ7698S
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FDQ7698S with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FDQ7698S with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FDQ7698S |
|---|---|
| Manufacturer | AMI Semiconductor / ON Semiconductor |
| Description | MOSFET 2N-CH 30V 12A/15A 14SOIC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | FDQ7698S | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | MOSFET 2N-CH 30V 12A/15A 14SOIC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4950 pcs | Data sheet | FDQ7698S |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 3V @ 250µA |
| Supplier Device Package | 14-SO | Series | PowerTrench® |
| Rds On (Max) @ Id, Vgs | 7.5 mOhm @ 15A, 10V | Power - Max | 1.1W, 1.3W |
| Packaging | Tape & Reel (TR) | Package / Case | 14-SOIC (0.154", 3.90mm Width), 11 Leads, Fused Leads |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 1324pF @ 15V | Gate Charge (Qg) (Max) @ Vgs | 17nC @ 5V |
| FET Type | 2 N-Channel (Dual) | FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 30V | Detailed Description | Mosfet Array 2 N-Channel (Dual) 30V 12A, 15A 1.1W, 1.3W Surface Mount 14-SO |
| Current - Continuous Drain (Id) @ 25°C | 12A, 15A |
