FDMS86500DC
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FDMS86500DC with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FDMS86500DC with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FDMS86500DC |
|---|---|
| Manufacturer | AMI Semiconductor / ON Semiconductor |
| Description | MOSFET N CH 60V 29A 8-PQFN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $1.274 | $1.136 | $0.932 | $0.755 | $0.636 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | FDMS86500DC | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | MOSFET N CH 60V 29A 8-PQFN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 52150 pcs | Data sheet | FDMS86500DC |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 4.5V @ 250µA |
| Vgs (Max) | ±20V | Technology | MOSFET (Metal Oxide) |
| Supplier Device Package | Dual Cool™56 | Series | Dual Cool™, PowerTrench® |
| Rds On (Max) @ Id, Vgs | 2.3 mOhm @ 29A, 10V | Power Dissipation (Max) | 3.2W (Ta), 125W (Tc) |
| Packaging | Original-Reel® | Package / Case | 8-PowerTDFN |
| Other Names | FDMS86500DCFSDKR | Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 39 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 7680pF @ 30V | Gate Charge (Qg) (Max) @ Vgs | 107nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 8V, 10V | Drain to Source Voltage (Vdss) | 60V |
| Detailed Description | N-Channel 60V 29A (Ta), 108A (Tc) 3.2W (Ta), 125W (Tc) Surface Mount Dual Cool™56 | Current - Continuous Drain (Id) @ 25°C | 29A (Ta), 108A (Tc) |
