FDMB3800N
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy FDMB3800N with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy FDMB3800N with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | FDMB3800N |
|---|---|
| Manufacturer | AMI Semiconductor / ON Semiconductor |
| Description | MOSFET 2N-CH 30V 4.8A MICROFET |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 100 pcs | 500 pcs | 1000 pcs |
|---|---|---|---|---|---|
| $0.412 | $0.359 | $0.277 | $0.205 | $0.164 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | FDMB3800N | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | MOSFET 2N-CH 30V 4.8A MICROFET | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 125711 pcs | Data sheet | FDMB3800N |
| Category | Discrete Semiconductor Products | Vgs(th) (Max) @ Id | 3V @ 250µA |
| Supplier Device Package | 8-MLP, MicroFET (3x1.9) | Series | PowerTrench® |
| Rds On (Max) @ Id, Vgs | 40 mOhm @ 4.8A, 10V | Power - Max | 750mW |
| Packaging | Cut Tape (CT) | Package / Case | 8-PowerWDFN |
| Other Names | FDMB3800NCT | Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 39 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 465pF @ 15V | Gate Charge (Qg) (Max) @ Vgs | 5.6nC @ 5V |
| FET Type | 2 N-Channel (Dual) | FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 30V | Detailed Description | Mosfet Array 2 N-Channel (Dual) 30V 4.8A 750mW Surface Mount 8-MLP, MicroFET (3x1.9) |
| Current - Continuous Drain (Id) @ 25°C | 4.8A |
