DC803A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DC803A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DC803A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DC803A |
|---|---|
| Manufacturer | ADI (Analog Devices, Inc.) |
| Description | BOARD EVAL FOR LTC3736EUF |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | ||||
|---|---|---|---|---|---|
| $54.933 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | DC803A | Manufacturer | ADI (Analog Devices, Inc.) |
|---|---|---|---|
| Description | BOARD EVAL FOR LTC3736EUF | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 541 pcs | Data sheet | LTspice FlyerLTspice IV Getting Started GuideLTC3736-1DC803A Quick Start Guide |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 1.8V, 2.5V |
| Voltage - Input | 2.75 V ~ 8 V | Utilized IC / Part | LTC3736-1 |
| Supplied Contents | Board(s) | Series | - |
| Regulator Topology | Buck | Outputs and Type | 2, Non-Isolated |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 8 Weeks |
| Main Purpose | DC/DC, Step Down | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Frequency - Switching | 550kHz | Detailed Description | LTC3736-1 - DC/DC, Step Down 2, Non-Isolated Outputs Evaluation Board |
| Current - Output | 5A, 5A | Board Type | Fully Populated |
| Base Part Number | LTC3736 |
