DC2204A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DC2204A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DC2204A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DC2204A |
|---|---|
| Manufacturer | ADI (Analog Devices, Inc.) |
| Description | DEMO BRD PSM UMODULE POWER STICK |
| Lead Free Status / RoHS Status | Not applicable / Not applicable |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | DC2204A | Manufacturer | ADI (Analog Devices, Inc.) |
|---|---|---|---|
| Description | DEMO BRD PSM UMODULE POWER STICK | Lead Free Status / RoHS Status | Not applicable / Not applicable |
| Quantity Available | 4654 pcs | Data sheet | LTC2974DC2204A Demo ManualLTM4620ALTM4677 DatasheetLTM4675LTM4676A Datasheet |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 0.7V, 0.85V, 0.9V, 0.95V, 1V, 1.2V, 1.5V |
| Voltage - Input | 4.5 V ~ 15 V | Utilized IC / Part | LTC2974, LTM4620A, LTM4675, LTM4676A, LTM4677 |
| Supplied Contents | Board(s) | Series | µModule® |
| Regulator Topology | - | Outputs and Type | 7, Non-Isolated |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Main Purpose | DC/DC Converter |
| Lead Free Status / RoHS Status | Not applicable / Not applicable | Frequency - Switching | - |
| Detailed Description | LTC2974, LTM4620A, LTM4675, LTM4676A, LTM4677 µModule® DC/DC Converter 7, Non-Isolated Outputs Evaluation Board | Current - Output | 36A, 13A, 13A, 13A, 13A, 9A, 9A |
| Board Type | Fully Populated |
