DC2154A
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy DC2154A with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy DC2154A with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | DC2154A |
|---|---|
| Manufacturer | ADI (Analog Devices, Inc.) |
| Description | EVAL BOARD FOR LTM8056 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 100 pcs | |||
|---|---|---|---|---|---|
| $23.585 | $23.239 | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | DC2154A | Manufacturer | ADI (Analog Devices, Inc.) |
|---|---|---|---|
| Description | EVAL BOARD FOR LTM8056 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1437 pcs | Data sheet | DC2154A Demo ManualLTspice FlyerLTspice IV Getting Started GuideLTM8056 Datasheet |
| Category | Development Boards, Kits, Programmers | Voltage - Output | 24V |
| Voltage - Input | 7 V ~ 58 V | Utilized IC / Part | LTM8056 |
| Supplied Contents | Board(s) | Series | µModule® |
| Regulator Topology | Buck-Boost | Outputs and Type | 1, Non-Isolated |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 26 Weeks |
| Main Purpose | DC/DC, Step Up or Down | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Frequency - Switching | 525kHz | Detailed Description | LTM8056 µModule® DC/DC, Step Up or Down 1, Non-Isolated Outputs Evaluation Board |
| Current - Output | 3A | Board Type | Fully Populated |
| Base Part Number | LTM8056 |
