ADUM7223CCCZ-RL7
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ADUM7223CCCZ-RL7 with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ADUM7223CCCZ-RL7 with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ADUM7223CCCZ-RL7 |
|---|---|
| Manufacturer | ADI (Analog Devices, Inc.) |
| Description | DGTL ISO 2.5KV GATE DRIVER 13LGA |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1000 pcs | ||||
|---|---|---|---|---|---|
| $0.901 | |||||
- Product parameter
- Data sheet
Product parameter
| Part Number | ADUM7223CCCZ-RL7 | Manufacturer | ADI (Analog Devices, Inc.) |
|---|---|---|---|
| Description | DGTL ISO 2.5KV GATE DRIVER 13LGA | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 40389 pcs | Data sheet | ADUM7223 |
| Category | Isolators | Voltage - Supply | 4.5 V ~ 18 V |
| Voltage - Isolation | 2500Vrms | Voltage - Forward (Vf) (Typ) | - |
| Technology | Magnetic Coupling | Supplier Device Package | 13-LGA (5x5) |
| Series | iCoupler® | Rise / Fall Time (Typ) | 12ns, 12ns |
| Pulse Width Distortion (Max) | - | Propagation Delay tpLH / tpHL (Max) | 62ns, 62ns |
| Packaging | Tape & Reel (TR) | Package / Case | 13-VFLGA |
| Other Names | ADUM7223CCCZ-RL7-ND ADUM7223CCCZ-RL7TR |
Operating Temperature | -40°C ~ 125°C |
| Number of Channels | 2 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Manufacturer Standard Lead Time | 7 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Detailed Description | 4A Gate Driver Magnetic Coupling 2500Vrms 2 Channel 13-LGA (5x5) |
| Current - Peak Output | 4A | Current - Output High, Low | - |
| Common Mode Transient Immunity (Min) | 50kV/µs | Base Part Number | ADUM7223 |
| Approvals | - |
