ADUM5020-5BRWZ
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy ADUM5020-5BRWZ with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy ADUM5020-5BRWZ with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | ADUM5020-5BRWZ |
|---|---|
| Manufacturer | ADI (Analog Devices, Inc.) |
| Description | DC DC CONVERTER 3KV 500MW |
| Lead Free Status / RoHS Status | RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 47 pcs | 141 pcs | 517 pcs | 1034 pcs |
|---|---|---|---|---|---|
| $2.652 | $2.283 | $1.982 | $1.726 | $1.503 | |
- Product parameter
- Data sheet
Product parameter
| Part Number | ADUM5020-5BRWZ | Manufacturer | ADI (Analog Devices, Inc.) |
|---|---|---|---|
| Description | DC DC CONVERTER 3KV 500MW | Lead Free Status / RoHS Status | RoHS Compliant |
| Quantity Available | 22777 pcs | Data sheet | ADuM5020, ADuM5028 |
| Category | Power Supplies - Board Mount | Voltage - Output 4 | - |
| Voltage - Output 3 | - | Voltage - Output 2 | - |
| Voltage - Output 1 | 5V, 3.3V | Voltage - Isolation | 3kV |
| Voltage - Input (Min) | 4.5V | Voltage - Input (Max) | 5.5V |
| Type | Isolated Module | Supplier Device Package | 16-SOIC |
| Size / Dimension | 0.41" L x 0.30" W x 0.10" H (10.3mm x 7.5mm x 2.7mm) | Series | IsoPower®, iCoupler® |
| RoHS Status | RoHS Compliant | Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Operating Temperature | -40°C ~ 125°C | Number of Outputs | 1 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Manufacturer Standard Lead Time | 8 Weeks | Features | OTP, UVLO |
| Efficiency | 33% | Detailed Description | Isolated Module DC DC Converter 1 Output 5V, 3.3V 100mA 4.5V - 5.5V Input |
| Current - Output (Max) | 100mA | Applications | ITE (Commercial) |
