Home > Products > Switches > DIP Switches > 90HBW04RT

90HBW04RT

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 90HBW04RT with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	90HBW04RT
Manufacturer	Grayhill, Inc.
Description	SWITCH SLIDE DIP SPST 25MA 24V
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 30735 pcs
Reference Price (In US Dollars)	750 pcs
Reference Price (In US Dollars)	$0.991

Product parameter
Data sheet

Product parameter

Part Number	90HBW04RT	Manufacturer	Grayhill, Inc.
Description	SWITCH SLIDE DIP SPST 25MA 24V	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	30735 pcs	Data sheet	90HB Series Datasheet
Category	Switches	Washable	No
Voltage Rating	24VDC	Termination Style	Gull Wing
Series	90HB	Pitch	0.100" (2.54mm), Full
Packaging	Tape & Reel (TR)	Operating Temperature	-40°C ~ 85°C
Number of Positions	4	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	3 (168 Hours)	Mechanical Life	2,000 Cycles
Manufacturer Standard Lead Time	12 Weeks	Length	0.470" (11.94mm)
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Height Above Board	0.190" (4.83mm)
Features	-	Electrical Life	2,000 Cycles
Detailed Description	Dip Switch SPST 4 Position Surface Mount Slide (Standard) Actuator 25mA 24VDC	Current Rating	25mA
Contact Material	Copper Alloy	Contact Finish	Gold
Circuit	SPST	Body Material	Thermoplastic
Actuator Type	Slide (Standard)	Actuator Level	Flush, Recessed
