Home > Products > Discrete Semiconductor Products > Diodes - Rectifiers - Arrays > VS-52CPQ030-N3

VS-52CPQ030-N3

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy VS-52CPQ030-N3 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	VS-52CPQ030-N3
Manufacturer	Electro-Films (EFI) / Vishay
Description	DIODE ARRAY SCHOTTKY 30V TO247AC
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 14063 pcs
Reference Price (In US Dollars)	500 pcs
Reference Price (In US Dollars)	$2.197

Product parameter
Data sheet

Product parameter

Part Number	VS-52CPQ030-N3	Manufacturer	Electro-Films (EFI) / Vishay
Description	DIODE ARRAY SCHOTTKY 30V TO247AC	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	14063 pcs	Data sheet	VS-52CPQ030PbF(-N3)
Category	Discrete Semiconductor Products	Voltage - Forward (Vf) (Max) @ If	550mV @ 50A
Voltage - DC Reverse (Vr) (Max)	30V	Supplier Device Package	TO-247AC
Speed	Fast Recovery = 200mA (Io)	Series	-
Packaging	Tube	Package / Case	TO-247-3
Other Names	VS52CPQ030N3	Operating Temperature - Junction	150°C (Max)
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	34 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Diode Type	Schottky	Diode Configuration	1 Pair Common Cathode
Detailed Description	Diode Array 1 Pair Common Cathode Schottky 30V 25A Through Hole TO-247-3	Current - Reverse Leakage @ Vr	1.9mA @ 30V
Current - Average Rectified (Io) (per Diode)	25A
