Home > Products > Circuit Protection > TVS - Diodes > SMF13A-E3-08

SMF13A-E3-08

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SMF13A-E3-08 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	SMF13A-E3-08
Manufacturer	Electro-Films (EFI) / Vishay
Description	TVS DIODE 13V 21.5V DO219AB
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	250 pcs	500 pcs	1000 pcs
~~In Stock~~ 630546 pcs
Reference Price (In US Dollars)	1 pcs	10 pcs	25 pcs	100 pcs
	$0.173	$0.128	$0.112	$0.073
	$0.06	$0.048	$0.037

Product parameter
Data sheet

Product parameter

Part Number	SMF13A-E3-08	Manufacturer	Electro-Films (EFI) / Vishay
Description	TVS DIODE 13V 21.5V DO219AB	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	630546 pcs	Data sheet	SMF5V0A - SMF58A
Category	Circuit Protection	Voltage - Reverse Standoff (Typ)	13V
Voltage - Clamping (Max) @ Ipp	21.5V	Voltage - Breakdown (Min)	14.4V
Unidirectional Channels	1	Type	Zener
Supplier Device Package	DO-219AB (SMF)	Series	-
Power Line Protection	No	Power - Peak Pulse	200W
Packaging	Cut Tape (CT)	Package / Case	DO-219AB
Other Names	SMF13A-E3-08GICT	Operating Temperature	-65°C ~ 175°C (TJ)
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	42 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Current - Peak Pulse (10/1000µs)	9.3A	Capacitance @ Frequency	423pF @ 1MHz
Applications	General Purpose
