KDH3BNA1BBB
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy KDH3BNA1BBB with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy KDH3BNA1BBB with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | KDH3BNA1BBB |
|---|---|
| Manufacturer | Cherry Switches (ZF Electronics) |
| Description | SWITCH ROCKER DPDT 16A 125V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | 1 pcs | 10 pcs | 25 pcs | 50 pcs | |
|---|---|---|---|---|---|
| $1.792 | $1.707 | $1.622 | $1.537 | ||
| 100 pcs | 250 pcs | 500 pcs | 1000 pcs | ||
| $1.515 | $1.473 | $1.409 | $1.238 | ||
- Product parameter
- Data sheet
Product parameter
| Part Number | KDH3BNA1BBB | Manufacturer | Cherry Switches (ZF Electronics) |
|---|---|---|---|
| Description | SWITCH ROCKER DPDT 16A 125V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 31374 pcs | Data sheet | KD Series Datasheet |
| Category | Switches | Voltage Rating - DC | 28V |
| Voltage Rating - AC | 125V | Termination Style | Quick Connect - 0.187" (4.7mm) |
| Switch Function | On-On | Series | KD |
| Panel Cutout Dimensions | Circular - 20.00mm Dia | Packaging | Bulk |
| Other Names | CH940 | Operating Temperature | -25°C ~ 85°C |
| Mounting Type | Panel Mount, Snap-In | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mechanical Life | 100,000 Cycles | Manufacturer Standard Lead Time | 18 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Illumination Voltage (Nominal) | - | Illumination Type, Color | - |
| Features | - | Electrical Life | 6,000 Cycles |
| Detailed Description | Rocker Switch DPDT 16A (AC), 10A (DC) 125V Panel Mount, Snap-In | Current Rating | 16A (AC), 10A (DC) |
| Color - Actuator/Cap | Black | Circuit | DPDT |
| Actuator Type | Round | Actuator Marking | No Marking |
