2SC4703-AZ
OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy 2SC4703-AZ with confidence from Components-World.HK, 1 Year Warranty
See Product Specifications for product details.
Buy 2SC4703-AZ with confidence from Components-World.HK, 1 Year Warranty
Request a Quote
| Part Number | 2SC4703-AZ |
|---|---|
| Manufacturer | CEL (California Eastern Laboratories) |
| Description | RF TRANSISTOR NPN SOT-89 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Reference Price (In US Dollars) | Get a quote | ||||
- Product parameter
- Data sheet
Product parameter
| Part Number | 2SC4703-AZ | Manufacturer | CEL (California Eastern Laboratories) |
|---|---|---|---|
| Description | RF TRANSISTOR NPN SOT-89 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5528 pcs | Data sheet | NE46234, 2SC4703 |
| Category | Discrete Semiconductor Products | Voltage - Collector Emitter Breakdown (Max) | 12V |
| Transistor Type | NPN | Supplier Device Package | SOT-89 |
| Series | - | Power - Max | 1.8W |
| Packaging | Strip | Package / Case | TO-243AA |
| Operating Temperature | 150°C (TJ) | Noise Figure (dB Typ @ f) | 2.3dB @ 1GHz |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Gain | 8.3dB |
| Frequency - Transition | 6GHz | Detailed Description | RF Transistor NPN 12V 150mA 6GHz 1.8W Surface Mount SOT-89 |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 50 @ 50mA, 5V | Current - Collector (Ic) (Max) | 150mA |
This browser does not support inline PDFs. Please download the PDF to view it: Download PDF
