Home > Products > Integrated Circuits (ICs) > PMIC - Full, Half-Bridge Drivers > SA57AHU

SA57AHU

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy SA57AHU with confidence from Components-World.HK, 1 Year Warranty

Dowload SA57AHU Details in PDF

Request a Quote

Part Number	SA57AHU
Manufacturer	Apex Microtechnology
Description	IC MOTOR DRIVER PAR 44HSOP
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

~~In Stock~~ 3370 pcs
Reference Price (In US Dollars)	1 pcs
Reference Price (In US Dollars)	$9.125

Product parameter
Data sheet

Product parameter

Part Number	SA57AHU	Manufacturer	Apex Microtechnology
Description	IC MOTOR DRIVER PAR 44HSOP	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	3370 pcs	Data sheet	SA57A
Category	Integrated Circuits (ICs)	Voltage - Supply	4.5 V ~ 5.5 V
Voltage - Load	9 V ~ 60 V	Technology	DMOS
Supplier Device Package	44-HSOP	Series	Apex Precision Power®
Rds On (Typ)	300 mOhm	Packaging	Bulk
Package / Case	44-BSSOP (0.433", 11.00mm Width) Exposed Pad	Output Configuration	Half Bridge (2)
Other Names	598-1812 598-2080 598-2080-ND SA57AHU-FH	Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	3 (168 Hours)
Manufacturer Standard Lead Time	9 Weeks	Load Type	Inductive
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Interface	PWM
Features	-	Fault Protection	Current Limiting, Over Temperature, Shoot-Through, UVLO
Detailed Description	Half Bridge (2) Driver DC Motors, General Purpose, Solenoids, Stepper Motors DMOS 44-HSOP	Current - Peak Output	17A
Current - Output / Channel	8A	Base Part Number	SA*
Applications	DC Motors, General Purpose, Solenoids, Stepper Motors
