Home > Products > Transformers > Power Transformers > L01-6345

L01-6345

OMRON AUTOMATION & SAFETYImages are for reference only.
See Product Specifications for product details.
Buy L01-6345 with confidence from Components-World.HK, 1 Year Warranty

Request a Quote

Part Number	L01-6345
Manufacturer	AlfaMag Electronics (AMGIS)
Description	XFRMR TOROIDAL 10VA THRU HOLE
Lead Free Status / RoHS Status	Lead free / RoHS Compliant

	100 pcs	260 pcs	500 pcs
~~In Stock~~ 7265 pcs
Reference Price (In US Dollars)	1 pcs	20 pcs	40 pcs	60 pcs
	$7.634	$5.817	$5.362	$5.181
	$5.09	$4.908	$4.726

Product parameter
Data sheet

Product parameter

Part Number	L01-6345	Manufacturer	AlfaMag Electronics (AMGIS)
Description	XFRMR TOROIDAL 10VA THRU HOLE	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	7265 pcs	Data sheet	L01 Series Datasheet
Category	Transformers	Weight	0.556 lb (252.2g)
Voltage - Secondary (Full Load)	Parallel 22V, Series 44V	Voltage - Primary	115V, 230V
Voltage - Isolation	4000Vrms	Type	Toroidal
Termination Style	PC Pin	Size / Dimension	55.00mm L x 55.00mm W
Series	L01	Secondary Winding(s)	Dual
Primary Winding(s)	Dual	Power - Max	10 VA
Other Names	L016345 TE2249	Mounting Type	Through Hole
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	20 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Height - Seated (Max)	26.00mm
Current - Output (Max)	Parallel 454mA, Series 227mA	Center Tap	No
